GSE Portrait 1840 – 1135 (Half Frame – 2 Per Panel)

NEW PRODUCT RANGE – 2022 GSE trays are different to the usual – please take the time to read the manual and understand, and ensure you’re using Easy-PV or the GSE configurator to ensure the correct trays are selected.

These new products have evolved from the 2012 and 2022 versions and are now delivered in two physical parts per module, rather than one. This listing is just for one half.

Key Features

• Easy to install
• Compatible with range of standard panels
• Lightweight at 2-3kg /m²
• 100 percent recyclable materials

This system goes together quickly and easily. The plastic trays that interlock are fixed to battens, with the roof tiles fitting up to the flashing. The panels are then hooked onto the trays and clamped into place.

The GSE system has trays to suit almost all common panel sizes – please check the attached Tolerance Table for further information. This panel is suitable for bigger size Eurener 480 and 500w panels.

Please use Easy-PV or send us your panel layout and we will specify the components that you will need.

Ref: ART105211

Datasheet

Installation Guide

Certifications

Batten Plan

Tolerance Table

Manual 50mm Battens

Manual 100mm Battens
