Renusol Console+ (Plastic Mount Only)

Description

The ConSole+ provides an angle of 15 degrees and can be fitted to flat roofs with a pitch of up to 5 degrees. Most commercially available framed standard PV modules fit on the ConSole.

The ConSole is weighed down with ballast. Any material can be used: gravel, paving slabs, bricks, rocks etc. The amount of ballast depends on the height and location of the building. Please see Page 5 of the installation manual “Preparing the Assembly – Point 2” in the table.

Mounting components are included for framed PV-modules. The modules attach to the mounts using the mounting holes on the back of the module. Please check the measurements below against your panel specification:

Max module length: 1550-2150 mm
Holes gap – width: 895-1014 mm
Holes gap – length: 690-1180 mm

Weight: 7.9kg

Pack includes:
1 x ConSole+ only

No fixings are included in this listing – select the console kit if you also require mounting bars and fixings .
